Galaxy Dimension GD-96 control panel. Integrated Intrusion and Access Control. Up to 16 independent protected areas. Up to 96 detection zones (16 zones on-board). Up to 32 doors. Up to 250 card holders per system. Up to 35 Weekly schedules. Supports up to 16 keypads. Support for graphical touch-screen keypad (2). Event logs for Access and Intrusion (up to 1000 and 1500 events respectively). Supports several communications options (PSTN, ISDN, Ethernet). Up to 16 Audio Verification (listen-in) channels. Single PC based central management solution. Enhanced interfacing protocol for system integration. Compliant to all relevant European standards. Fully compatible with existing Galaxy range-

IR Detector. Fresnel optic. Anti-pets. Range 12 x 17 m. Selectable pet immunity. Double temperature compensation. Opening tamper and take off. Easy opening and set up. Intelligent walking test system. Voltage: 9.0 - 15 V CC; traditionaly 7 mA. Dimensions: 9.8 x 5.7 x 4.35 cm. Operating temperature from -10°C to 55°C. Relative humidity from 5 to 93% (Without condensation). Security grade 2 certified.

Designed for mid to high-end commercial environments where a Grade 3 system may be required, the DT8016AF4 anti-mask motion sensor delivers reliable protection with improved false alarm immunity through patented solutions. It includes DualCore™ signal processing which is ideal for areas that are difficult to protect with standard products and integrates a total of five patented solutions to improve reliability and installation. In addition to this, the installer will benefit from the design of the sensor which allows easy access to the connectors with its quick plug-in feature. Furthermore this motion sensor offers integrated EOL resistors and enhanced walk test feature saving time on installation. Optimum performance is achieved using X-Band microwave technology and Uniform Sensitivity Optics. Range 16 x 22 m.

LightSYS™ board with 8 zones, expandable up to 50 wireless zones, and up to 32 bus detectors. Grade 2 certificate. LightSYS™ 2 is compatible with VUpoint, the new real-time video-verification solution from RISCO™ Group. VUpoint is cloud-based and uses IP Cameras to provide real-time video streaming when an alarm is triggered or on demand. LightSYS™ 2 together with VUpoint offers an exclusive security solution for homes and businesses, while being flexible, reliable and easy to install. Professional security solution with video-verification that will increase your sales. Intuitive application for Smartphone that allows a simple control and notification of alarms anywhere with video-verification in real time. The flexibility of communications allows the use of IP, GSM / GPRS, PSTN and long range radio transmitters, all installed inside the main panel. Wide range of accessories and detectors available: wired, bidirectional and on the RISCO™ Bus.

Bracket for wall and ceiling for BWARE™ detectors.

Sensor: 1/3 4 megapixel CMOS. Infrared capability: Distance of 30 meters. Focal length: 2.8mm wide angle. Backlight management: WDR 120 dB. Firmware update via camera web interface. SD card slot. 12V DC / POE power supply (not included). Consumption: maximum 5.0 W. Operating conditions -40 ° C to 55 ° C. Dimensions: Diameter 70 x Length 162 mm. Degree of protection IP67. Requires RISCO™ NVR.

Passive infrared detector QUAD, reach 15 meters and antimasking. Internal protection of the PCB. Simple and elegant design with a single convex lens. Anti-masking by Active IR. Opto-relays for protection against the attack of large magnets. Tampers: cover and wall / corner. Corridor lenses (optional). BWare™ Wall / Ceiling Bracket RA51T (optional). Interior installation Power: 9 to 16 VDC. Maximum consumption: 41 mA. Dimensions: 127.6 x 64.2 x 46.6 mm.

Polycarbonate Stroboscopic Flash of medium power. IP65 protection. 12VDC Power supply. Consumption: 115mA. Working temperature from -30ºC to 70ºC. Dimensions: Ø75 x 51 mm. Xenon light. 60 blinks per minutes. Blue colour housing.

L support for contacts: DC110, DC115 and DC118.

Plastic magnetic contact for built-in assembly with magnet surface. Its provided with 4 wires cable of 2m. NC alarm and tamper contact. Maximum operational opening 12mm. Dimensions: 11 x 33 mm. Security grade 2 certified.

Magnetic aluminium contact for floor and doors mounting. Provided with 2 metres of 5 wire cable. NA and NC contacts. Maximum operational opening 9~62 mm. Magnet and contact Dimensions: 76 x 12 x 35 mm. Security grade 2 certified.

Plastic magnetic contact for surface mounting. Its provided with a 4 wires 2 meters cable. NC alarm and tamper contact. Maximum operational opening of 15mm. Dimensions: 51 x 9 x 9 mm. Security grade 2 certified.

Receiver module with 32 zones via radio plus 2 wired zones and a programmable relay output for Advisor Advanced control panels, fully supervised. Bus connection Frequency 433Mhz (Legacy *, 63-bit and LoNa * protocol). Working temperature from -10ºC to 55ºC. 12Vdc power Dimensions: 155x95x26mm. Grade 2.

Spectra™ Plus kit from 5 to 32 zones. Includes 1 SP4000 Central Board, bidirectional central of 4 zones (8 with ATZ), expandable to 32. 1 Large box (L-BOX), box with transformer and capacity for 12 VDC/7Ah battery (not included) and 1 K32LCD+ keyboard with 10-zone LEDs. Additionally: 4 dual-element digital NV5 IR detectors with antimasking capacities up to 16 kg, and 1 12VDC / 4.2 Amp battery.

Spectra™ Plus kit from 5 to 32 zones. Includes 1 SP4000 Central Board, bidirectional central of 4 zones (8 with ATZ), expandable to 32. 1 Large box (L-BOX), box with transformer and capacity for 12 VDC/7Ah battery (not included) and 1 K10H keyboard with 10-zone LEDs. Additionally: 4 dual-element digital NV5 IR detectors with antimasking capacities up to 16 kg, and 1 12VDC / 4.2 Amp battery.

Spectra™ Plus kit from 5 to 32 zones. Includes 1 SP4000 Central Board, bidirectional central of 4 zones (8 with ATZ), expandable to 32. 1 Small box (S-BOX), box with transformer and capacity for 12 VDC/7Ah battery (not included) and 1 TM50 5" touch keyboard.

Spectra™ Plus kit from 5 to 32 zones. Includes 1 SP4000 Central Board, bidirectional central of 4 zones (8 with ATZ), expandable to 32. 1 Small box (S-BOX), box with transformer and capacity for 12 VDC/7Ah battery (not included) and 1 K32LCD keyboard with 2-part LEDs.

Spectra™ Plus kit from 5 to 32 zones. Includes 1 SP4000 Central Board, bidirectional central of 4 zones (8 with ATZ), expandable to 32. 1 Small box (S-BOX), box with transformer and capacity for 7Ah battery (not included) and 1 K10H keyboard with 10-zone LEDs.

Magellan™ Kit from 5 to 32 zones. Includes 1 MG5050 Hybrid Central of 5 Zones (10 with ATZ), expandable up to 32, with 868 MHz receiver via radio in a large box (L-BOX) with transformer included, with 12VDC/7Ah battery capacity (not included), and 1 TM50 5" tactile keyboard. Additionally, includes 3 PMD2P PIR detectors via radio with double element, with antimasking capacity of Up to 10kg, 1 REM15 remote button 5-channel, waterproof and 1 12VDC/4.2 Amp battery.

Magellan™ Kit from 5 to 32 zones. Includes 1 MG5050 Hybrid Central of 5 Zones (10 with ATZ), expandable up to 32, with 868 MHz receiver via radio in a large box (L-BOX) with transformer included, with 12VDC/7Ah battery capacity (not included), and 1 K32LCD + 2-partition keyboard. Additionally, includes 3 PMD2P PIR detectors via radio with double element, with antimasking capacity of Up to 10kg, 1 REM15 remote button 5-channel, waterproof and 1 12VDC/4.2 Amp battery.

Magellan™ Kit from 5 to 32 zones. Includes 1 MG5050 Hybrid Central of 5 Zones (10 with ATZ), expandable up to 32, with 868 MHz receiver via radio in a large box (L-BOX) with transformer included, with 12VDC/7Ah battery capacity (not included), and 1 K10H keyboard with 10-zone LEDs. Additionally, includes 3 PMD2P PIR detectors via radio with double element, with antimasking capacity of Up to 10kg, 1 REM15 remote button 5-channel, waterproof and 1 12VDC/4.2 Amp battery.

Magellan™ Kit from 5 to 32 zones. Includes 1 MG5050 Hybrid Central of 5 Zones (10 with ATZ), expandable up to 32, with 868 MHz receiver via radio in a large box (L-BOX) with transformer included, with 12VDC/7Ah battery capacity (not included), and 1 TM50 5" touch keyboard.

Magellan™ Kit from 5 to 32 zones. Includes 1 MG5050 Hybrid Central of 5 Zones (10 with ATZ), expandable up to 32, with 868 MHz receiver via radio in a large box (L-BOX) with transformer included, with 12VDC/7Ah battery capacity (not included), and 1 K32LCD + 2-partition keyboard.

Magellan™ Kit from 5 to 32 zones. Includes 1 MG5050 Hybrid Central of 5 Zones (10 with ATZ), expandable up to 32, with 868 MHz receiver via radio in a large box (L-BOX) with transformer included, with 12VDC/7Ah battery capacity (not included), and 1 K10H keyboard with 10-zone LEDs.
